Saturday, February 8, 2014

White Charcoal Sound - Binchotan musical instrument

Binchotan musical instrument  - White Charcoal Sound


bincho-tan or white charcoal, also known as bincho-zumi, is a traditional charcoal of japan. it dates back to the edo period, when a craftsman named bitchu-ya chozaemon began to produce it in tanabe, wakayama. the raw material is oak, called ubame oak (quercus phillyraeoides)

binchotan is almost as hard as steel, with a smooth surface when cut. when two pieces strike, a clear, metallic sound is emitted. binchotan is an excellent electrical conductor. it contains a variety of minerals that were absorbed during its life as tree. all trees have a porous structure, which is needed to absorb nutrients from soil. in just one cubic centimetre, binchotan contains billions of pores, for a total area that could cover a tennis court.

Hitting charcoal makes hard sound. Charcoal of different length makes different pitches, so a musical instrument can be made with charcoal.

Making Binchotan

binchotan is made by carbonizing oak wood at a moderately low temperature. near the end of the process, the kiln temperature is raised to approximately 1000° celsius, making the wood red hot. at their deep red stage, the embers must be quickly removed and smothered in powder to cool. the powder is a mixture of sand, earth, and ash, which results in a whitish color on the surface of the charcoal, hence the name white charcoal. the quick rise in temperature, followed by quick cooling, burns up the outer layer of the wood, leaving a smooth, hardened surface.

Saturday, October 26, 2013

Buy or sell charcoal and Charcoa briquettes in Vietnam

We're charcoal manufature and dealer in Vietnam, charcoal from many source will be sale at cheapest price here. If you wanna find charcoal or charcoal briquettes in Vietnam, please contact me by email at: nhatkhoa   @  gmail.com  ( please delete the space) or call me at +84937711777
 We curently making charcoal powder briquettes at lowest price only $300 per tons FOB Hochiminh city, Vietnam and can suppy over 300 tons per month



If you need sawdust briquettes charcoal, i still can find supplier, however, price would be over $600/ton FOB


we can also sell wood logs charcoal at $550/ton please look at below pictures



ghe chỏ than



Than bạch đàn nguyên cây

Than vụn nhỏ

Than nhãn

Than tạp bể

Than vỏ cây

than đước


Charcoal ExtruderCharcoal Extruder MachineCoal powder briquettes
OperatingCylinder Shape
(30,40,50mm)
Hexagon shape BriquetteSquare shape charcoal BriquetteFingure charcoal Briquettes
Hexagon Shape Briquette
(50mm)
Square Shape Briquettes
(50mm)
Fingure Charcoal Briquettes
(22mm)
1.2 Process Flow For Charcoal briquetting Plant (for reference)
Raw Material→ Grind milling → Mixing with binder → Conveyor →charcoal press
→Dryer (Not available) →Packing(Not available)→ Storage

Tieng Viet
Xin Kính gửi các anh chị báo giá than thang 11-2013 như sau:

Than củi đước loại nguyên cây :giá 10,500/kg
Than bạch đàn loại nguyên cây :7000/kg
Than nhãn loại nguyên cây :8400/kg

Than củi ép thanh từ than vụn : giá 5500/kg

Than cục nhỏ kích thước từ 3cm x 3cm trở lên 3500/kg

Than bụi ( gồm vỏ cây và các loại than bể nhỏ hơn 3cm ) 2000/kg

Mọi chi tiết xin liên hệ anh Khoa 0937711777 - 0916 971757

Tuesday, March 19, 2013

How to Make Charcoal Briquettes from Waste Materials

How to Make Charcoal Briquettes from Waste Materials


Charcoal made out of the modified pit method can be used in making charcoal briquettes. Charcoal briquettes are charcoal dust compactly massed by a binder of either cassava flour, corn or sweet potato starch.



As fuel, charcoal briquettes have higher heating value than wood or plain charcoal. They are almost smokeless when burning and give off intense and steady heat. They can be used in the smelting of iron ore since it is compact and dense.

Aside from their used as fuel, charcoal briquettes can be converted to otherindustrial products. In the chemical industry, they are used in the manufacture of carbon disulfide, carbon electrodes, carbon tetrachloride, carbon carbide, sodium cyanide and activated charcoal for purifying air or water.

See Video clip Make charcoal briquettes from agricultural waste



Materials and Equipment

To make the charcoal briquettes, you need well-charred charcoal made throughthe modified pit method and cassava corn or camote starch as binder.

Hammer mill or wooden mallets, pail, mild and a tapahan type dryer are also needed.


View Video Clips Charcoal Briquette Machine from Coconut Shell
Procedure

Charcoal briquettes can be produced manually or mechanically. For a small-scale briquettes maker, the manual method will suffice. The method is simple and can easily applied in places where coconuts abound.

First, prepare or have ready smokeless charcoal. This type of charcoal is shiny and gives a metallic sound when tapped. Powder the charcoal into dust particles by hammering with a mallet or wooden hammer or by passing through a hammer mill.

Cook cassava corn or camote starch under moderate heat. The starch should have a syrupy consisting which is neither too thick nor too thin. This will be used as binder.

Mix thoroughly the charcoal dust and the binder in a pail or any available container. When the mixture has reached an even consistency, knead in the same ways making dough for bread.

Molding the resulting mixture into desired shape and size using the hands or an improved wooden molder such as a sungkahan.

The dry briquettes under the sun. Better still, oven cook them in an improvement tapahan type dryer using pieces of wood, coconut shells and dusks and other waste materials for fuel.

Making of charcoal briquettes can be practically costly if undertaken in areas where coconut shells or other suitable materials are discard as waste.

Materials for Briquetting

Only materials which would produce soft and poor quality charcoal should be used for charcoal briquetting. It is not advisable to convert hard charcoal into charcoal briquette. Big charcoal manufacturing establishments, could put up charcoal briquettting units to convert charcoal fine and small broken charcoal particles into briquettes.

Studies show that in charcoal manufacturing establishments, fine waste constitutes 10 to 15 percent of usable charcoal. To ensure a smokeless charcoal briquette, the charcoal fine must be well-charged, that is, it must contain at least 75 percent fixed carbon and not more than 24 percent volatile matter.

For big scale (one ton per hour and up) briquetting, charcoal fines and lump charcoal may be combined as raw materials.

Materials recommended for charcoal briquetting are:

  1. Charcoal fines accumulated during charcoal manufacturing, handling, and transporting;

  2. charcoal from low-density wood and bulky materials like coconut husks, corn cobs, etc.;

  3. charcoal from wood wastes during logging, lumbering and veneering such a log ends, stumps, branches, twigs, barks and trimmings;

  4. charcoal from the fine agro-forestry waste materials such as sawdust, ricehull, and coconut coir dust; and

  5. charcoal from tree plantations.

These materials abound in the country. Their use in charcoal briquetting creates jobs and generates more income and recycles waste in the countryside into a useful commodity.

Binders for Charcoal Briquetting

1. Smokeless binders :

  • Meal binders such as cassava starch, corn starch, and other starches are smokeless but not moisture resistant. they are normally used in the range of 4 to 6 percent on the oven-dry basis. In some cases, small amounts of moisture resistant binders are used.

2. Smoky binders :

  • Smoky but moisture resistant binders are tar, pitch, asphalt, sugar cane molasses, and others. Recommended percentage for wood- tar pitch and coal-tar pitch is less than 30 percent. Briquettes with these blinders are smoky when ignited. But this characteristic is not a drawback for briquettes used in smelting and heating. For home use it could be very annoying.

Manufacture of Charcoal Briquettes

a. Mechanical Process

Charcoal is manufactured either mechanically or manually. A lot- size briquetting machine installed at the Forest Products Research and Development Institute (FPRDI) produces better quality briquettes faster. The steps in manufacturingcharcoal briquettes are:

a1. Preparation of Charcoal Fines:

Use charcoal material with low moisture content and high fixed carbon content. If lump charcoal is used, pass these through a primary crusher, then through a disintegrator. This process is skipped if charcoal is fine like those obtained from sawdust, rice hull, and other agro-forestry fine materials such as those accumulated during charcoal manufacturing.

a2. Mixing Charcoal Fines with Binder

Charcoal fines is mixed with binder which could be any of gelatinized starch of pastry consistency, liquid tar, molasses, or heated asphalt. Mixing usually use a kneader type, double- shaft mixer. This process is one of the most critical operations in the manufacture of charcoal briquettes. Efficient mixing is essential to obtain a strong product.

a3. Briquetting of the Mixture

After thorough mixing of charcoal fines and the binders, mixture is fed into the molds where pressure is applied to make the particles compact. The size and shape of the briquettes go with the molds. The most common is the ovoid-type or pillow-shaped briquettes.

a4. Drying of the Briquettes

Briquettes are dried first before packaging, to make them strong. They are dried in a batch-type or continuous dryer.

b. Manual Process

For small-scale briquette manufacturing, the manual method is recommended. Although, this method is time-consuming and produces irregularly shaped briquettes, it is good alternative for small- scale operators who cannot afford an expensive briquetting unit. It is also ideal for housewives and amateur charcoal briquettes makers who are willing to experiment.

The same operations and principle used in the mechanical method are applied in the manual method. The only difference is the use of the hand in the manual technique.

First, the charcoal fines and binder are separately prepared. Charcoal fines are pulverized into soft or low quality charcoal with a hammer or mallet. The binder is made by simply sun-drying sliced cassava or sweet potato for about one week the pulverizing them until they turn into starch. Corn starch may also be used. It is cooked into a syrup consistency, neither too thick nor too thin.

In a pail or any suitable container, mix thoroughly the charcoal fine and the binder by kneading. The mixture is molded into desired shapes and sizes by hand. An improvised wooden molder may also be used.

Dry the molded briquettes under the sun for about three days. Or better still, dry them in an improvised “tapahan” type dryer fueled by wood, coconut shell or husk or other waste material. When the briquette moisture goes down to 10 percent, the briquettes are removed from the dryer.

source: region10.dost.gov.ph, photo from commons.wikimedia.org

How To Make Bamboo Charcoal Briquettes

To fully utilize the bamboo, another technology was generated that could help the standowners produce more income. Wastes from bamboo processing may be manufactured into charcoal briquettes. This could help reduce pressure on wood resource. It could also help mitigate carbon dioxide emission into the atmosphere.



The steps in making kawayan charcoal briquettes are:


1. Collecting and Preparing the Raw Materials

  • Collect dead poles and branches from bamboo clumps. Oftentimes, these materials are left to rot or burned during clearing and cleaning operation of bamboo stands.

  • Collect waste materials for use in making charcoal briquette. Bamboo processing leaves excessive waste materials such as trimmings and shavings. Generally, about 20-40% are thrown into waste when processing bamboo into furniture and engineered products.

  • Collect chichacorn effluent. Collect and store in plastic containers the chichacorn processing effluent from the first and third washing of the boiled corn kernels. The first washing effluent contains 4. 48% TSS mostly lime while the third washing contains 3.08% TSS mostly starch.

2. Carbonizing is the process of converting the raw bamboo into charcoal. It can be done through drum method. Cool-off the charred materials in closed metal containers. An alternative to the drum is the pit method.

  • Dig a small pit approximately 1m2 and 0.5 m deep and place the raw bamboo materials inside.

  • Start lighting a fire into the wastes bamboo materials and then put rice hull little by little into it until the fire is gone and the wastes materials are completely charred and carbonized.

  • Cool-off charred materials in metal containers.

3. Shredding/Pulverizing

  • Shred or pulverize the charcoal to attain uniform sized particles. This will facilitate the even mixing of the binders and the charcoal fine particles.

4. Preparing the Binder – The use of chichacorn effluent as binders is recommended. It is cheap because it is considered waste material.

  • Mix 2.5 L of effluent to one kg of charcoal. Where effluent is not available, use corn starch as a binder.

  • Use 6% mixture This means that 1 kg of bamboo charcoal needs 60 g of gelatinized corn starch. The weight of water of the raw material.

5. Briquetting

  • Mix thoroughly the binder and the charcoal.

  • Mold into briquettes immediately.

6. Drying the Briquettes

  • Dry the briquettes under the sun for 1-2 days.

  • Continue drying under the shade until it reaches equilibrium moisture content.

7. Packaging

  • Pack the briquettes according to desired size and weight. For the 3.78 cm diameter x 4.88 cm length briquettes, approximately 40 pieces are equivalent to 1 kg. Wrap the briquettes with used cement bags, which could be used later to fire up the briquettes.

source: PCARRD-DOST, ILARRDEC, MMSU






 Bamboo Charcoal Briquettes











 source: http://charcoalkiln.com/bamboo-charcoal-briquettes/
